Fenix LD20 R5 LED Flashlight

The Fenix LD20 is an outdoor flashlight for multiple uses. It offers multiple brightness levels that allow you to choose whether you need brightness or runtime. There are 4 constant-brightness levels and 2 flashing outputs to choice from. Its portable, compact size and the water-proofing of the IPX-8 standard make the LD20 a dependable flashlight for your lighting applications plus emergency use.

Features and Specifications

Cree XP-G R5 LED with lifespan of 50,000 hours

Two modes (6 types) of output, generation/turbo selected by turning the bezel (patented)

Output (rated to ANSI FL-1 spec) / Runtime:

General Mode: 5 lumens (100 hrs) -> 30 lumens (15 hrs) -> 81 lumens (5hrs 57min) -> SOS

Turbo Mode: 180 lumens (2hrs 16min) -> Strobe

Max beam length: 110 meters

Digitally regulated output - maintains constant brightness

Uses 2 x Ni-MH AA Batteries (Batteries not included)

NOTE: Ni-MH Batteries recommended. Flashlight will operate with 2 x Alkaline AA cells but some modes will not work!

Dimensions: 5.9" (150mm) (Length) x 0.85" (21.5mm) (Diameter)

Made of durable aircraft-grade aluminum

Premium Type-III hard-anodized anti-abrasive finish

Weight: 2.12 oz (60 g) weight (excluding batteries)

Waterproof to IPX-8 Standards (underwater 2 meters)

Toughened ultra-clear glass lens with anti-reflective coating

Push-button tail cap switch

Capable of standing up securely on a flat surface to serve as a candle

Anti-roll, slip-resistant body design

Included Accessories: holster, lanyard, body clip, two spare O-rings, and a rubber switch boot

UPC: 6942870300894

Operating Instructions

Fully press (click) to switch on and turn the bezel to select General Mode or Turbo Mode. A soft-press (without clicking) while the light is on will change the brightness

levels of the current mode. Turning the light off for more than 2 seconds will restore the default setting.

Note: Do not use Li-Ion 14500 batteries or it will damage the light engine.

SPECIFICATIONS

Turbo High Medium Low Moonlight Lumens: 180 81 30 5 5 Runtime (Hours): 2.27 5.95 15 100 100 Output Modes: 3+ Brightness Levels, Strobe Compatible Batteries: 2 x AA Batteries Included: No Included Accessories: Holster, Lanyard, Pocket Clip, Spare O-ring(s) Flashlight Usage: Every Day Carry Throw Distance (Max): 110m LED: CREE XP-G R5 Switch Location: Tailcap Product Certifications: ANSI, IPX-8 Brand: Fenix
